Module Type:Pulse Train Output

Model:FM562

Application Voltage Range:24-48V DC

Output Current:Up to 2A

Number of Channels:2

Communication Interface:Modbus TCP/IP

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +85°C

Dimensions (WxHxD):144.2 x 45.5 x 88.2 mm

Weight:0.22 kg

    The ABB FM562 Pulse Train Output Module is engineered to meet the stringent requirements of high-speed, precision control tasks within the industrial automation sector. It excels in generating and synchronizing precise pulses, making it an indispensable component for systems requiring accurate timing and sequence control.

    Featuring an operating frequency range from 10 Hz to 20 kHz, the module ensures compatibility and performance across a wide spectrum of applications. With an output current rating of up to 100 mA, it provides sufficient power for most industrial control scenarios, while its low power consumption contributes to energy efficiency.

    Equipped with a MODBUS RTU communication interface, the FM562 facilitates seamless integration with various industrial networks, enhancing system flexibility and connectivity. Its robust temperature and storage capabilities (-25°C to +60°C for operation, -40°C to +85°C for storage) ensure reliable performance under diverse environmental conditions.

    The IP20 enclosure protection class offers basic protection against dust and splashes, ensuring the module's durability and safety in industrial environments. Compact yet lightweight, with dimensions of 96 mm x 96 mm x 40 mm and a weight of approximately 0.2 kg, the FM562 is designed for easy installation and maintenance.

    Whether you're looking to enhance the precision of your control systems, synchronize processes in complex machinery, or integrate seamlessly with existing industrial networks, the ABB FM562 Pulse Train Output Module is the solution you need. It combines advanced technology with reliability, offering a cost-effective upgrade for your automation projects.
