Manufacturer:ABB

Model Number:5SHX0845F0001

Order Number:3BHL000385P0101

Type:IGCT Module

Module Series:5SHX

Operating Frequency:Up to 60 kHz

Peak Current:25 kA

RMS Current:10 kA

Switching Voltage:DC 1000 V

Insulation Class:F

Circuit Configuration:Single phase

Control System Compatibility:ABB ACS880 series drives

Environmental Rating:IP21

Material:Aluminum and copper alloys

Size (D x W x H):240 x 100 x 100 mm

Weight:4.5 kg

    Introducing the ABB 5SHX Series 0845F0001 IGCT Module, an indispensable component for modern industrial systems requiring robust power management capabilities. This high-performance module is engineered for exceptional reliability and efficiency in a wide range of applications, including renewable energy integration, electric vehicle charging stations, and high-power distribution networks.

    Crafted with cutting-edge technology, the 5SHX Series boasts superior switching characteristics, enabling seamless operation across various voltage levels. Its compact design, combined with a lightweight structure, facilitates easy installation and maintenance without compromising on performance.

    Equipped with advanced protective features, this IGCT module ensures optimal system safety by preventing overvoltage and short-circuit conditions. Its wide temperature range and IP20 environmental rating guarantee reliable operation under diverse environmental conditions.

    The ABB 5SHX Series 0845F0001 IGCT Module leverages ABB’s extensive expertise in power electronics, ensuring long-lasting durability and minimal downtime. It is compatible with a variety of control systems, offering seamless integration and enhanced operational flexibility.

    Experience unparalleled performance and reliability with the ABB 5SHX Series 0845F0001 IGCT Module. Trust in ABB’s commitment to innovation and excellence for your most demanding power management challenges.
