Product Overview

• PN:DSPC170｜Alternate No:57310001-GL / 57310001-KH｜Brand:ABB｜Series:Advant OCS / Advant Master DCS｜Type:Dual-Core Main CPU Processor Module

• Definition:High-performance dual-core central processing unit dedicated to ABB classic Advant OCS open distributed control system, undertakes full plant real-time PID loop regulation, safety interlock logic operation, batch sequence control and multi-bus communication scheduling, core original spare for outdated thermal power, petrochemical DCS control rack overhaul and main controller failure emergency replacement

•


Core Features

• 85MHz dual-core real-time industrial processor architecture, separate cores for control logic and communication processing to eliminate task delay
• Built-in 8MB program memory + 1MB high-speed data memory, supports complex multi-loop continuous process control and historical trend data storage
• Multi integrated bus interfaces: internal SBus rack bus, CNet control network, expandable Profibus DP communication via matched interface card
• Independent hardware full self-diagnosis circuit, front panel multi-color LED indicators for power supply, running status, bus link and module fault quick onsite inspection
• Supports 1+1 redundant hot backup master-slave switching, seamless switchover without process shutdown for high-reliability continuous production occasions

• Standard Eurocard rack plug-in structure, directly inserted into DSBB175 dedicated Advant Master backplane, supports offline module replacement

•


Technical Specs

• Auxiliary supply:24VDC ±10% control power supply
• Processor frequency:85MHz dual-core
• Storage:8MB program ROM, 1MB data RAM
• Internal rack bus:SBus proprietary backplane bus
• Operating temp:-20℃~+60℃｜Storage:-40℃~+85℃,RH5%~95% non-condensing
• Net weight:0.915kg｜Dimension:340×235×32mm
• HS Code:85389091

• Certification:CE, UL certified

•


Compatibility

Perfectly matched with ABB Advant Master DSBB175 rack backplane, compatible with DCP02/DCP10 auxiliary control modules, S400/S600 I/O units, CI520V1 AF100 communication card; incompatible with S800 I/O, 800xA DCS, AC500 PLC and ACS series frequency converters

Application

• Spare replacement for aging thermal power, chemical plant, papermaking, metallurgy factory Advant OCS DCS main control cabinet

• High-performance controller upgrade and main CPU breakdown emergency maintenance for continuous process production lines

•


Our Advantage

• Full control program loading, long-cycle logic operation and multi-bus communication continuous aging testing before shipment
• 12-month global warranty for all stocked products
• DHL/Fedex worldwide door-to-door delivery
• Free technical support for rack backplane matching, program download, redundant configuration and bus wiring debugging
