Product Overview

• PN:07KT97B｜Alternate No:GJR5253000R0162｜Brand:ABB｜Series:Advant AC500 / AC800M Symphony Plus｜Type:ARCNET Bus Communication Module
• Definition:Dedicated ARCNET coaxial fieldbus communication card for ABB AC800M controller and Symphony Plus Harmony distributed control system, establishes stable ARCNET network connection between main CPU, remote I/O stations, HMI panels and third-party process control equipment, realizes real-time cyclic control data transmission and acyclic parameter diagnosis, standard original spare for communication bus fault replacement and control system network expansion transformation

Core Features

• Compliant with standard ARCNET industrial coaxial bus protocol, high anti-interference transmission via RG6 coaxial cable, maximum single segment transmission distance up to 600 meters
• Built-in hardware signal isolation and surge suppression circuit, effectively resist electromagnetic interference in thermal power, petrochemical, metallurgy harsh industrial control environments
• Supports redundant ARCNET dual-bus wiring configuration, seamless communication switching without process control interruption for high-reliability continuous production sites
• Front panel multi-color LED indicators for power supply, ARCNET bus link status, data transmission and module fault quick on-site diagnosis
• Standard rack plug-in structure, directly inserted into AC800M controller rack, compatible with Symphony Plus Harmony control unit backplane without extra conversion accessories
• Compatible with serial debugging port, supports offline network parameter configuration and online bus signal monitoring

Technical Specs

• Auxiliary supply:24VDC ±10% control power supply
• Bus medium:RG6 coaxial cable
• ARCNET transmission rate:2.5Mbps fixed industrial bus speed
• Operating temp:-20℃~+70℃｜Storage:-40℃~+85℃,RH5%~95% non-condensing
• Net weight:0.6kg｜Dimension:136×110×40mm
• HS Code:85389091
• Certification:CE, UL, RoHS certified

Compatibility

Perfectly matched with ABB AC800M series controllers and Symphony Plus Harmony DCS platform, compatible with S800 I/O modules, CI810B Profibus communication cards and CP series HMI touch panels; incompatible with Advant S600 I/O, DCP series Freelance CPU, ACS frequency converters and IRC5 robot control cabinets

Application

• Spare replacement for aging thermal power plant, chemical factory, papermaking factory ABB Symphony Plus / AC800M DCS control cabinet
• ARCNET bus communication fault emergency repair and distributed multi-station network expansion renovation of continuous process production lines

Our Advantage

• Full ARCNET bus continuous communication aging testing before shipment
• 12-month global warranty for all stocked products
• DHL/Fedex worldwide door-to-door delivery
• Free technical support for controller rack matching, coaxial cable wiring and ARCNET network parameter configuration debugging
