DSQC627 3HAC020466-001 ABB IRC5 Robot Axis Computer Drive Unit Original In Stock

Short Description:

DSQC627 PN 3HAC020466-001 ABB IRC5 multi-axis computer drive board, original rob

Send email to us

Product Detail

DSQC627 PN 3HAC020466-001 ABB IRC5 multi-axis computer drive board, original robot spare parts with full functional aging test, 12-month global warranty for IRC5 robot servo communication & motion failure maintenance replacement

Product Overview

PN: DSQC627｜Part No:3HAC020466-001｜Brand:ABB｜Series:IRC5 Robot DSQC Servo Control Board｜Type:Axis Computer Board
Definition:Core axis motion control computer board for ABB IRC5 robot controller, responsible for real-time communication between mainboard DSQC602 and each single-axis servo amplifier. It processes encoder feedback signals, distributes motion trajectory commands, executes speed/position closed-loop control logic, and feeds back axis overload, overheat, encoder loss faults to teach pendant. Critical spare for robot axis jitter, motion alarm, axis communication breakdown overhaul.

Core Features

High-speed internal servo bus, synchronous data transmission with all axis power drives, ensures high-precision robot trajectory for welding, cutting, handling tasks
Independent signal processing circuit for each robot joint, separate fault diagnosis for every axis to quickly locate single-joint abnormal problems
Complete hardware protection: encoder disconnection detection, axis overload monitoring, over-temperature alarm, short-circuit interlock protection
Front panel multi LED status indicators: power supply, bus communication, axis running, fault alarm for fast on-site troubleshooting
Standard slide-in plug-in structure for IRC5 controller rack, supports offline replacement without damaging other cabinet modules
Built-in signal isolation and surge suppression, strong anti-electromagnetic interference for automobile welding, metal stamping harsh workshop environment

Technical Specs

Power input: 24VDC supplied by cabinet internal power module DSQC609
Communication interface: ABB proprietary servo bus connecting single-axis power amplifiers
Supported axes: Matches full 6-axis IRC5 robot joint drive system
Operating temp: -20℃ ~ +60℃｜Storage temp: -40℃ ~ +85℃, RH5%–95% non-condensing
Net weight: 0.37kg｜Dimension: 226 × 152 × 32mm
Protection grade: IP20 (cabinet internal installation only)
HS Code:85389091
Certification:CE, UL certified
Product status: Discontinued original spare, tested refurbished & surplus original stock available

Compatibility

Applicable Controllers: ABB IRC5 Single / IRC5 M2004 cabinet robot controllers
Applicable Robot Models: IRB1410, IRB2400, IRB2600, IRB4600, IRB6600, IRB6700, IRB7600 all standard IRC5 six-axis robots
Matching Internal Modules: DSQC602 main computer board, DSQC608 SMU measurement unit, DSQC609 24V power supply, DSQC327A mixed I/O module, DSQC series single-axis servo power amplifiers
Incompatible: IRC5 Compact / IRC5 Dual cabinet, OmniCore new robot controllers, S3/S4 legacy robot systems, Advant DCS S400/S600/S800 I/O, 800xA DCS, AC500 PLC, ACS inverters

Application

Spare replacement for robot faults: Axis communication lost, robot unable to move, joint vibration, overload alarm, encoder feedback error, motion system startup failure
Welding, spraying, machine tending, heavy load handling IRC5 robot workstation regular maintenance and cabinet renovation
Aging axis computer board replacement to eliminate random robot safety stop and trajectory deviation problems

Our Advantage

Full servo bus communication, multi-axis motion simulation long-cycle aging testing before shipment
12-month global warranty for all stocked original spare parts
DHL/Fedex worldwide door-to-door delivery, shipment port Xiamen
Free technical support for rack slot matching, servo bus wiring, axis fault code troubleshooting and robot motion calibration guidance
