5SHY3545L0009 ABB HiPak IGCT Press-Pack Power Module ACS1000 Medium Voltage Drive Core Power Device In Stock

Short Description:

ABB 5SHY3545L0009 4500V/3500A IGCT thyristor module, matched with ACS1000 high-v

Send email to us

Product Detail

ABB 5SHY3545L0009 4500V/3500A IGCT thyristor module, matched with ACS1000 high-voltage inverter, applied in power grid, new energy and large industrial motor drive.

Product Overview

Part Number: 5SHY3545L0009
Alternative codes: 3BHB013085R0001, GVC750BE101
Brand: ABB
Series: HiPak integrated gate commutated thyristor (IGCT) power semiconductor series
Type: Press-pack round wafer IGCT module with built-in freewheeling diode
FunctionActs as high-speed power switching core of medium-voltage inverters, converters and SVG reactive power compensation equipment. It realizes high-power AC/DC rectification, inversion and power flow control; switches on/off according to gate drive signals to adjust output voltage and frequency of high-power motors. It supports four-quadrant operation including motor soft start, speed regulation and regenerative braking, serving as the most critical power switching component for high-power electric energy conversion systems.

Core Features

High voltage & large current ratingRated blocking voltage 4500V, continuous rated current 3500A; 10ms surge current up to 6000A to cope with motor startup impact current. Integrated freewheeling diode eliminates extra diode configuration and simplifies power stack design.
Press-pack packaging advantageRound press-fit structure realizes double-sided heat dissipation, excellent thermal conductivity, convenient radiator installation; no internal bonding wire, strong anti-vibration capability, long service life in high vibration industrial sites. Low stray inductance reduces switching loss and electromagnetic interference.
Simplified peripheral circuitIGCT features hard commutation performance with no need for complicated RC buffer circuits, lowering cabinet design difficulty and fault probability. Conformal coated internal chips resist humidity and dust.
Complete protection compatibilityCooperates with ABB dedicated gate trigger boards to realize overvoltage, overcurrent, overtemperature and short-circuit hardware rapid protection.
Mature matching systemCustomized for ABB ACS1000 medium voltage inverter power stacks, fully compatible with original drive power unit layout.

Technical Specifications

Rated repetitive peak blocking voltage: 4500 V
Continuous RMS on-state current: 3500 A
Non-repetitive surge current (10ms): 6000 A
Operating junction temperature range: -40℃ ~ +125℃
Packaging form: Press pack (double-side cooling)
HS Code: 85413090
Supply: Brand new original and fully tested refurbished modules available
Certifications: CE, IEC power semiconductor standard certification

Compatibility

Main matching equipment: ABB ACS1000 medium voltage high-power frequency converter
Matched supporting accessories: 3BHB013085R0001 gate drive trigger board, GVC750BE101 power unit overall assembly
Applicable high-power equipment: Large fan, water pump, compressor, rolling mill main drive, arc furnace power supply
Direct interchange for all batches of 5SHY3545L0009; cross replacement available for same voltage/current HiPak IGCT models

Application

Maintenance replacement of damaged power devices on ACS1000 medium voltage inverters in metallurgy, chemical industry, mining
Wind power converter, photovoltaic grid-connected inverter high-power loop overhaul
Power plant SVG static var compensator, HVDC transmission auxiliary converter maintenance
Large industrial high-voltage motor drive system spare backup for regular maintenance
