Product Overview

• Part No: DSAI130D, full part number 3BSE003127R1
• Brand: ABB
• Series: Advant OCS / S100 I/O module, compatible with 800xA / AC800M DCS platform
• Type: Isolated differential analog input acquisition module

• FunctionConvert analog current and voltage signals from field transmitters, temperature, pressure, flow and liquid level sensors into digital data. Transmit collected signals to DCS main controllers for closed-loop regulation, real-time monitoring, trend recording and interlock protection. Differential wiring greatly eliminates on-site electromagnetic interference, stable for power, chemical and metallurgy strong interference workshops.

•


Core Features

• 16 fully differential input channels, channel-to-channel isolation, anti-crosstalk and noise resistance
• Multi-signal compatibility: 4-20mA, 0-20mA, 0~5V, 0~10V, ±5V, ±10V all configurable
• 12-bit high conversion resolution, basic measurement accuracy ±0.03% FS
• Optional hardware filter: 2ms/4ms/8ms/16ms four grades to filter high-frequency field clutter
• PCB conformal coating, dust-proof, moisture-proof, oil mist resistance, adapts harsh factory conditions
• Independent LED status indicators for power running, communication fault and channel abnormal alarms
• Standard rack plug-in card, backplane bus connection, easy hot swapping and cabinet maintenance

• Supports PROFIBUS DP bus communication with AC800M controllers

•


Technical Specifications

• Power Supply: DC 24V
• Operating Temperature: 0℃ ~ +55℃
• Storage Temperature: -25℃ ~ +85℃
• Humidity: 5%~95% non-condensing
• Net Weight: 0.52kg
• Protection Class: IP20 (cabinet internal installation only)
• HS Code: 85389091

• Supply: Brand new original & fully tested refurbished modules available

•


Compatibility

• Matched controllers: AC450, AC800M, full 800xA DCS control system
• Matched rack: ABB S800 I/O station base rack
• Compatible industries: thermal power plants, chemical plants, metallurgy, water treatment automation cabinets

• Direct one-to-one replacement for all batches of DSAI130D with identical part number

•


Application

• Replacement for aging analog acquisition cards in DCS cabinets with drifting readings and unstable signals
• Pressure, temperature, flow transmitter signal collection overhaul
• Boiler, pipeline, reactor closed-loop control system spare maintenance
• Retrofit and I/O expansion of legacy Advant DCS automation projects
