Emerson 5X00605G01 Ovation DCS 8-channel analog input module, collects 4–20mA field transmitter signals, maintenance spare for power plant automation control racks.

Product Overview

• Part No: 5X00605G01
• Brand: EMERSON / Westinghouse Ovation

• Category: 8-Channel Analog Input Module 5X00605G01 is an analog input module designed for Emerson Ovation distributed control system. It acquires standard 4–20mA and 1–5VDC analog signals from field instruments including pressure, flow and temperature transmitters, and converts analog signals into digital data for Ovation controllers to execute closed-loop process regulation. Every channel adopts independent signal conditioning circuit with galvanic isolation to suppress electromagnetic interference from field side. The module supports hot swapping for online replacement without system shutdown. Front panel LED indicators display module operating state and channel fault alarms for convenient on-site inspection. It serves as critical maintenance spare for overhaul and retrofit of thermal power plant boiler, turbine and auxiliary control systems.

•


Core Features

• 8 isolated analog input channels, compatible with 4–20mA and 1–5VDC signals
• High-resolution AD conversion to guarantee steady measurement precision
• Galvanic isolation between field circuit and internal control bus
• Hot-swap supported, modules can be replaced online without system power-off
• Built-in surge and overvoltage protection for each signal channel
• Front panel LED indicators for module status and channel fault diagnosis
• Standard Ovation rack plug-in design for quick installation and replacement

• Industrial hardware design meeting strict EMC requirements for power station environment

•


Technical Specifications

• Input Channels: 8 channels
• Supported Signals: 4–20mA DC, 1–5 VDC
• Power Supply: Powered via Ovation rack backplane
• Operating Temperature: -20°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Mounting: Ovation standard rack slot installation

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Fully compatible with Emerson Ovation DCS racks and matching controller hardware
• Widely deployed in thermal power plants, combined-cycle power stations, water treatment and petrochemical industries
• Collect process variable signals for boiler, turbine auxiliary monitoring and closed-loop control
