Emerson CE4003S2B1 (KJ3222X1-BA1) DeltaV S-Series 8-channel HART analog input module, collects 4–20mA signals from smart transmitters, maintenance spare for process DCS automation.

Product Overview

• Part No: CE4003S2B1, KJ3222X1-BA1
• Brand: EMERSON

• Category: 8-Channel HART Analog Input Module CE4003S2B1 (KJ3222X1-BA1) is an S-Series analog input module for Emerson DeltaV distributed control system. It acquires 4–20mA analog signals from field pressure, flow, temperature transmitters and supports HART 7 protocol for bidirectional communication with smart instruments. The module executes high-precision A/D conversion and transmits process variable data to DeltaV controllers for closed-loop control. Independent galvanic isolation is equipped for each channel to suppress electromagnetic interference from field wiring. Hot-swap capability allows online module replacement without interrupting system operation. Front panel LED indicators display module status, communication activity and channel faults to facilitate fast field troubleshooting. It serves as key spare part for maintenance and upgrade of petrochemical, power and water treatment control systems.

•


Core Features

• 8 isolated analog input channels supporting 4–20mA DC signals
• Native HART 7 communication for smart instrument configuration, diagnosis and data retrieval
• High-resolution A/D conversion to ensure stable measurement accuracy
• Channel-to-channel and channel-to-ground galvanic isolation
• Hot-swap supported for online maintenance without system shutdown
• Built-in comprehensive channel self-diagnosis including open-circuit detection
• Front panel LED indicators for module health and channel alarm status
• Snap-in pluggable design matching DeltaV S-Series I/O carrier
• Wide temperature range hardware suitable for control room and field-mounted cabinets

• Compliant with strict industrial EMC standards for continuous 24/7 operation

•


Technical Specifications

• Input Channels: 8 channels
• Input Signal: 4–20mA DC, HART 7 compatible
• Power Supply: Powered via DeltaV I/O carrier backplane
• Operating Temperature: -40°C ~ +70°C
• Storage Temperature: -40°C ~ +85°C
• Mounting: DeltaV S-Series standard I/O carrier installation

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Fully compatible with Emerson DeltaV S-Series I/O carriers and DeltaV controllers
• Widely deployed in oil & gas, petrochemical, thermal power plants, pharmaceutical and water treatment industries
• Applied for continuous acquisition of process variables from HART field transmitters for loop regulation and plant monitoring
