Emerson 5X00106G01 Ovation DCS 8-channel high performance HART analog input module, acquires 4–20mA signals from smart field transmitters, critical spare for power plant and process automation control systems.

Product Overview

• Part No: 5X00106G01
• Brand: EMERSON / Westinghouse Ovation

• Category: 8-Channel High Performance HART Analog Input Module 5X00106G01 is a high-performance analog input module developed for Emerson Ovation distributed control system. It receives standard 4–20mA DC signals from pressure, flow and temperature smart transmitters and supports HART protocol for bidirectional digital communication with field instruments. High-speed A/D conversion ensures rapid and accurate collection of process variables for closed-loop regulation. Each channel is equipped with independent galvanic isolation to suppress field electromagnetic interference. The module supports hot-swap function for online replacement without system shutdown. Front panel LED indicators display module running state, communication activity and channel faults to facilitate fast on-site troubleshooting. It serves as key maintenance spare for boiler, turbine and auxiliary process control loops in thermal power plants.

•


Core Features

• 8 isolated high-speed analog input channels compatible with 4–20mA DC signals
• Native HART communication support for smart instrument configuration, diagnosis and data access
• High precision high-speed sampling to satisfy demanding process control requirements
• Galvanic isolation between field wiring and internal control bus
• Hot-swap capable for online maintenance without interrupting system operation
• Built-in comprehensive self-diagnosis including open-circuit and short-circuit detection
• Front panel LED indicators for module health and channel alarm status
• Standard plug-in design matching Ovation I/O rack base assembly

• Industrial-grade hardware satisfying strict EMC standards for power station environments

•


Technical Specifications

• Input Channels: 8 channels
• Input Signal: 4–20mA DC, HART protocol compatible
• Power Supply: Powered via Ovation rack backplane
• Operating Temperature: -20°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Mounting: Ovation standard rack slot installation

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Fully compatible with Emerson Ovation DCS racks, controllers and supporting base assemblies
• Widely deployed in thermal power plants, combined-cycle power stations, petrochemical and water treatment industries
• Applied for continuous acquisition of process variables from HART field transmitters for monitoring and closed-loop control
