Artesyn PMC-IO-ADAPTER rear transition I/O adapter, routes PMC mezzanine card P4 user I/O signals via VME P2 backplane, matched for MVME6100 / MVME7100 series 6U VME single board computer, extends PMC external signal wiring for embedded control systems.

Product Overview

• Part No: PMC-IO-ADAPTER
• Brand: ARTESYN (Formerly Motorola / Emerson Embedded Computing)

• Category: PMC Rear I/O Transition Adapter PMC-IO-ADAPTER is a dedicated rear transition module designed for MVME6100, MVME7100 series 6U VME single-board computers. It serves as signal routing bridge between VME backplane P2 connector and PMC mezzanine card P4 user I/O interface. The adapter extracts all user-defined I/O signals from PMC slot, breaking signals out to rear panel connectors for external field wiring. It supports single-wide PMC modules, conforms to VITA P35 PMC rear I/O routing specification. It solves the limitation that VME CPU board cannot directly lead out PMC rear I/O signals, widely used to expand serial communication, analog/digital I/O, fieldbus and custom peripheral interfaces on legacy VME control platforms. It is essential spare component for power plant control, industrial real-time automation and test measurement equipment renovation.

•


Core Features

• Specialized rear transition adapter for PMC P4 user I/O signal breakout
• Conforms to VITA 35 PMC rear I/O routing standard, pin-to-pin signal transmission
• Routes signals between VME P2 backplane and PMC slot P4 connector
• Compatible with single-wide standard PMC mezzanine modules
• Passive signal routing board, no active processing chip, low signal attenuation
• Standard 6U VME rear transition form factor, installed on chassis rear side
• Supports hot-swap compatible VME chassis configuration
• Robust PCB layout with impedance control for stable high-speed signal transmission

• Wide temperature industrial hardware for long-term 24/7 continuous operation

•


Technical Specifications

• Form Factor: 6U VME rear transition module (RTM)
• Signal Standard: VITA 35 PMC P4 rear I/O mapping
• Interface: VMEbus P2 connector, PMC I/O dedicated connector
• Supported Host SBC: MVME6100, MVME7100 series VME single board computer
• Supported Module: Single-wide PMC mezzanine card
• Circuit Type: Passive routing adapter
• Operating Temperature: 0°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Humidity: 5%–95% non-condensing

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Compatible Host: MVME6100, MVME7100 series 6U VME PowerPC single board computer
• Matched expansion: Serial PMC, analog I/O PMC, fieldbus PMC modules
• Widely deployed in thermal power control systems, industrial embedded automation, accelerator test equipment
• Applied for expanding external signal access of PMC mezzanine boards in legacy VME control racks
