Foxboro FBM233 (P0926GX) Ethernet communication module for I/A Series DCS, connects up to 64 field devices with 10/100Mbps Ethernet, supports redundant deployment for process automation.

Product Overview

• Part No: FBM233, P0926GX
• Brand: Foxboro (Invensys / Schneider Electric)
• Category: Ethernet Field Device Integration Module

• FBM233 P0926GX is an Ethernet‑based field device integrator module for Foxboro I/A Series DCS system. It adopts 10/100Mbps Ethernet interface, supports connection to maximum 64 external field devices, achieves up to 2000 DCI block connections. It can be configured for redundant master‑tracker operation, transfers field device data into DCS control database. Widely used in petrochemical, power plant and oil‑gas process control sites.

•


Core Features

• • 10/100 Mbps copper Ethernet communication via RJ45 port
• • Supports redundant master‑tracker pairing for high‑availability operation
• • Connects up to 64 field devices, maximum 2000 DCI block connections
• • Downloadable software drivers for multi‑protocol field device integration
• • Class G3 harsh‑environment rated, supports field‑mount installation
• • Front‑panel LED indicators for module status and fault diagnosis

• • Hot‑swap capable for convenient on‑site maintenance and replacement

•


Technical Specifications

• • Platform: Foxboro I/A Series DCS
• • Communication: 10/100 Mbps Ethernet RJ45
• • Power Supply: 24 VDC ±10%
• • Power Consumption: Max 3W
• • Environment Class: G3 harsh industrial grade
• • Protection Class: IP20
• • Operating Temperature: -20℃ ~ +70℃

• • Application: Petrochemical, power generation, oil & gas process automation

•


Compatibility

• Compatible with I/A Series controllers FCP270, FCP280, FCM100E, FCM100Et
• Works with Foxboro Evo control system database
• Supports integration of third‑party Ethernet‑capable field instruments
