Operating Voltage:120 V AC / 24 V DC

Input Range:-10 V to +10 V

Resolution:12 bits

Sampling Rate:50 kHz

Accuracy:+/- 0.1% + 2 LSB

Environmental Temperature Range:-25°C to +60°C

Number of Channels:4

Package Dimensions:100 mm x 100 mm x 40 mm

Weight:0.3 kg

    The ABB AI845-EA 3BSE023675R2 Analog Input Module is engineered to deliver exceptional performance in demanding industrial environments. It supports up to eight simultaneous input channels, enabling versatile integration into various control systems. With a high-resolution 16-bit analog-to-digital converter, this module ensures accurate and reliable signal conversion, crucial for precise data acquisition in automation processes.

    Featuring a wide signal range from -10V to +10V, it can accommodate a broad spectrum of sensor outputs, making it suitable for diverse applications across different industries. Its sampling rate of 10 kHz allows for real-time monitoring and control, enhancing system responsiveness.

    Efficient power management ensures low energy consumption without compromising performance, making it an eco-friendly choice for industrial automation. The module operates within a temperature range of -20°C to +60°C, ensuring reliability in varying environmental conditions.

    Equipped with an RS485 connection, the AI845-EA provides robust communication capabilities, facilitating seamless data transfer between devices. Its compact dimensions of 100mm x 90mm x 40mm make it easy to integrate into existing systems without taking up excessive space.

    Designed with durability and ease of use in mind, this ABB module is a valuable asset for engineers seeking to enhance their automation systems with advanced, yet straightforward solutions. It comes with comprehensive documentation and support, ensuring a smooth installation and operation process.
