HIMA H6200A is the core safety CPU module for HIMax safety instrumented system, adopting 2oo2D fault-tolerant architecture, certified SIL3 per IEC61508, used for ESD, F&G and BMS safety control in oil, gas and power industry.

Product Overview

The HIMA H6200A is a high-performance safety central processor module belonging to HIMA HIMax safety platform. It adopts 2-out-of-2 diversified (2oo2D) dual processor fault-tolerant architecture, two independent processors run safety logic simultaneously and cross-compare results continuously. This module executes safety control programs, processes field I/O signals, performs real-time fault diagnosis and safety communication. It supports hot swap and redundant network configuration, serves as core controller of SIS system for emergency shutdown, fire & gas monitoring and burner management in hazardous industrial sites.

Key Features

• 2oo2D diversified dual safety processor fault-tolerant architecture
• SIL3 safety certification compliant with IEC 61508 / IEC 61511
• Dual Ethernet ports for redundant communication and engineering access
• Supports PROFIsafe, Modbus TCP and HART communication protocols
• Comprehensive self-diagnosis, fault detection and event logging
• Hot swappable design for online module replacement without system shutdown
• Rack plug-in installation, match HIMax series chassis and I/O modules
• Industrial rugged hardware, stable operation under harsh field environment

• LED status indicators for quick system status and fault check

•


Technical Specifications

• Brand: HIMA
• Model: H6200A
• System Platform: HIMax Safety Instrumented System
• Safety Level: SIL3 (IEC 61508)
• Architecture: 2oo2D diversified dual processor
• Communication: Dual Ethernet, internal backplane bus
• Power supply: 24VDC
• Mounting: HIMax rack plug-in module
• Operating temperature: -20℃ ~ +70℃

• Certification: TÜV, CE, ATEX

•


Compatibility & Application

Compatible with HIMax rack, H6110A digital input, H6120A analog output and other HIMax series I/O modules. Widely used in oil & gas, refinery, LNG terminal, chemical plant, power plant for ESD emergency shutdown system, F&G fire and gas system, BMS burner management system and turbine safety protection.
