Honeywell CC-PUIO31 is a Series-C universal I/O module for Experion PKS C300 controller, with 32 software configurable channels, supports HART 7, SOE, electronic short-circuit protection, suitable for hazardous area process control.

Product Overview:

Honeywell CC-PUIO31 is a flexible universal I/O module of Honeywell Experion Series-C platform, matched with C300 controller. It has 32 software configurable channels, each channel can be set as AI, AO, DI or DO freely. It supports HART 7 communication and 1ms SOE sequence of event recording, built-in electronic short-circuit protection to avoid module damage from field short circuit. This module works with CC-TUIO31 non-redundant or CC-TUIO41 redundant IOTA base, simplifies cabinet design and reduces spare part types for process plants.

Key Features:

• 32 software configurable universal channels, AI/AO/DI/DO optional per channel
• Support HART 7 protocol for smart field instruments
• 1ms resolution SOE function for event sequence capture
• Electronic short-circuit protection, single channel fault isolated
• Extended operating temperature: -40℃ ~ +70℃
• Hazardous location certification for Zone 2 / Div 2 non-incendive wiring
• Support redundant I/O link, hot swap available
• Built-in channel open-wire detection and comprehensive diagnostics

• Compatible with CC-TUIO31 and CC-TUIO41 IOTA terminal bases

•


Technical Specifications:

• Brand: Honeywell
• Model: CC-PUIO31
• Series: Experion PKS Series-C
• Compatible Controller: C300
• Total Channels: 32 configurable channels
• Protocol: HART 7, IOLink
• SOE Resolution: 1ms
• Temperature Range: -40℃ ~ +70℃
• Matching IOTA: CC-TUIO31 (non-redundant), CC-TUIO41 (redundant)

• Installation: Rack slot mount

•


Compatibility & Application:

It is widely used in petrochemical, oil & gas, power, pulp and paper, chemical process control, compatible with Honeywell Experion PKS DCS system for field signal acquisition and control output.
