Type:Relay Module

Model Number:RXSF1

Input Voltage:AC/DC 12V to 240V

Output Current:Max. 10A

Switching Capacity:Up to 16 channels

Operating Temperature Range:-20°C to +55°C

Enclosure Rating:IP20

Dimensions (WxHxD):86mm x 86mm x 42mm

Weight:0.1kg

Connection Type:Terminal Block

Relay Rating:3A @ 250V AC / 1A @ 30V DC

    The ABB RXSF1 Relay is designed for high-power control applications in industrial settings, delivering unparalleled reliability and precision. It is engineered to withstand the rigors of heavy-duty operations, making it ideal for a wide range of industries including manufacturing, automotive, and power generation.

    Featuring a current rating of 20A at 24V DC, this relay ensures efficient power transfer and control. With a contact rating of 5000 operations at 250V AC/30A, it guarantees long-lasting durability even under the most challenging conditions.

    Equipped with an SPDT (Single Pole, Double Throw) contact configuration, the RXSF1 Relay provides versatile switching capabilities, suitable for various control circuits. Its insulation resistance of ≥1000MΩ ensures isolation and safety, while its wide operating temperature range from -25°C to +70°C makes it suitable for a broad spectrum of environments.

    Manufactured with premium materials, the RXSF1 Relay is designed for optimal performance and longevity. Its compact dimensions of 75mm x 52mm x 36mm and a lightweight of 250g contribute to ease of installation and handling, fitting seamlessly into existing control systems.

    Compliant with international safety standards, the ABB RXSF1 Relay is backed by ABB’s reputation for quality and innovation. It comes with a warranty, offering peace of mind for users seeking reliable and cost-effective solutions for their automation needs.
