Module Type:Earth Fault Monitoring System

Model Number:3BHE003604R0102 UP C765 AE102

Operating Voltage Range:100V to 690V AC

Monitoring Capacity:Up to 128 circuits

Protection Levels:ISO 9001:2015 Certified

Operating Temperature:-25°C to +70°C

Environmental Compliance:UL/IEC/EN

Dimensions (WxHxD):160mm x 115mm x 85mm

Weight:0.5kg

    Introducing the ABB 3BHE003604R0102 UP C765 AE102 Earth Fault Monitor Board, a cutting-edge technology designed to safeguard industrial electrical systems against potential hazards. This board is meticulously engineered to offer unparalleled accuracy in earth fault detection, ensuring swift action is taken to prevent critical system failures and downtime.

    Featuring an expansive operational voltage range from 120V to 480V AC, this monitor board is versatile enough to integrate seamlessly into a variety of industrial settings. Its robust design withstands temperatures ranging from -5°C to +40°C, making it suitable for challenging environments across multiple industries.

    With a protection class of IP20, the ABB 3BHE003604R0102 ensures reliable operation in non-hazardous locations, safeguarding against dust and splashing water. The compact dimensions of 173mm x 104mm x 42mm and a weight of just 0.5kg facilitate easy installation without compromising on functionality.

    Equipped with Modbus RTU communication interface, this monitor board enables seamless integration with existing control systems, enhancing efficiency through real-time data exchange. The inclusion of two relay outputs allows for immediate action upon detection of earth faults, mitigating risks and preventing potential damage to the electrical infrastructure.

    In summary, the ABB 3BHE003604R0102 UP C765 AE102 Earth Fault Monitor Board stands as a testament to ABB's commitment to innovation and safety. Its combination of advanced detection capabilities, wide operational range, and reliable design makes it an indispensable component in safeguarding industrial electrical systems.
