Manufacturer:ABB

Model:2UBA002322R0001

Series:High-Voltage Inverter Power Unit

Control Board Type:Power Management

Operating Voltage Range:690V AC

Operating Frequency:40-60 Hz

Protection Class:IP54

Dimensions (LxWxH):445mm x 160mm x 90mm

Weight:5.8kg

Input Current:160A

Output Current:160A

Load Capacity:Up to 10 MW

Communication Interfaces:RS485, Ethernet

Operating Temperature Range:-20°C to +50°C

Storage Temperature Range:-30°C to +70°C

    Crafted with precision, the ABB 2UBA002322R0001 control board offers unparalleled reliability and efficiency in managing high-voltage inverter power units. Designed to withstand harsh industrial environments, it ensures seamless integration and superior performance under varied operating conditions.

    With an extensive range of communication interfaces, including RS485 and Ethernet, the control board facilitates smooth data exchange and control over the inverter system, enhancing operational flexibility and connectivity.

    Engineered for durability and longevity, the IP54 protection class ensures the board can operate effectively in dusty and wet environments, reducing downtime and maintenance costs.

    Featuring a wide operating temperature range from -20°C to +50°C and a storage range from -30°C to +70°C, the ABB 2UBA002322R0001 is designed for global deployment across various geographical locations.

    The control board comes equipped with advanced diagnostics and monitoring capabilities, providing real-time insights into system performance and enabling proactive maintenance, thus optimizing energy usage and enhancing overall operational efficiency.
