Board Type:PCB Circuit Board

Application Type:Motor Control

Model Number:SNAT7780CNT

Brand:ABB

Input Voltage Range:380V-460V AC

Operating Temperature:-20°C to +50°C

Dimensions:150mm x 100mm

Weight:0.5kg

Certifications:CE, UL, CSA

    The ABB SNAT7780CNT PCB circuit board is engineered to deliver superior performance in motor control systems across various industries. Its compact design ensures easy integration into existing setups while its robust materials withstand harsh environmental conditions.

    Equipped with advanced circuitry, this board supports high-speed, precise control, making it ideal for applications requiring fine-grained adjustment and dynamic load handling. The integrated RS-485 interface facilitates seamless communication with other control systems, enhancing system efficiency.

    Withstanding temperatures from -20°C to +70°C, the SNAT7780CNT is designed for operation in extreme environments without compromising performance. Its IP20 protection level ensures dust resistance and limited water ingress, maintaining reliability in industrial settings.

    Built using high-grade copper-clad laminate, the board offers excellent electrical conductivity and heat dissipation capabilities, crucial for maintaining peak operational efficiency over extended periods. The board's lightweight design and standardized dimensions make it compatible with a wide range of mounting solutions.

    The ABB SNAT7780CNT comes with comprehensive documentation and technical support, ensuring quick setup and smooth operation. It is backed by ABB’s industry-leading warranty, providing peace of mind for users seeking long-term reliability and cost-effective maintenance solutions.
