Power Rating:1500W

Operating Temperature Range:-40°C to +175°C

Insulation Class:Class 1

Switching Frequency:up to 20kHz

Input Voltage Range:DC 200V to DC 1200V

Output Current:up to 300A

    The ABB 5SNG015045P0301 IGBT module is engineered to deliver exceptional performance in industrial control systems. Its robust design ensures longevity and reliability under challenging conditions, making it an indispensable component for modern industrial automation.

    Featuring a state-of-the-art power rating, this module is capable of handling high-power demands with ease, ensuring smooth operation even in the most demanding applications. Its high switching frequency allows for precise control and reduced energy consumption.

    Withstanding extreme environmental conditions from -40°C to +125°C, this IGBT module is designed for versatile use across various industries, including manufacturing, automotive, and renewable energy sectors. The insulation class F guarantees safety and protection against high temperatures.

    For optimal cooling and maintenance, the ABB 5SNG015045P0301 employs an air-cooled system, ensuring efficient heat dissipation and minimizing downtime. Its mechanical life of 100,000 switching operations underscores its durability and reliability, surpassing industry standards.

    Equipped with advanced diagnostic features, this IGBT module enables easy monitoring and maintenance, facilitating quick troubleshooting and reducing operational costs. It is compatible with a wide range of control systems, ensuring seamless integration into existing industrial infrastructures.
