Form Factor:Compact PCB

Connector Type:Industry-standard 9-pin D-sub

Supported Channels:16 channels

Sampling Rate:250 kHz

Input Range:-10V to +10V

Resolution:12-bit ADC

Power Consumption:2.5W

Operating Temperature:-40°C to +85°C

Dimensions:100mm x 50mm x 10mm

Operating Voltage:DC 12V

Communication Interface:RS-485

    The Honeywell 8C-PAIH54 Differential Card is designed to provide unparalleled precision in industrial control systems. Its differential input type ensures accurate signal differentiation, which is essential for maintaining optimal operational efficiency and enhancing system reliability in various applications.

    Featuring an exceptionally wide operating temperature range from -40°C to +70°C, this card is built to withstand harsh environmental conditions, making it suitable for use in extreme climates without compromising performance.

    With a response time of less than 1 millisecond, the 8C-PAIH54 Differential Card ensures rapid processing and responsiveness, crucial for systems requiring immediate action in response to input changes.

    Equipped with a ±0.1% of full scale accuracy, this card delivers exceptional measurement precision, vital for industries where accuracy is paramount, such as manufacturing, robotics, and process control.

    Built with an RS-485 interface, the card offers reliable data communication, enabling seamless integration with other control systems and devices. This interface ensures robust connectivity, facilitating the exchange of data and commands over longer distances with minimal interference.

    Compact yet durable, the 8C-PAIH54 Differential Card measures 76mm x 51mm x 20mm and weighs only 25g, ensuring it fits into tight spaces without adding unnecessary bulk. Its lightweight and small size make it an ideal choice for space-constrained applications without compromising on functionality.
