Operating Voltage:DC 24V

Input Type:Pulse

Channel Count:4

Signal Compatibility:TTL, CMOS

Response Time:≤ 1ms

Load Capacity:Up to 2A per channel

Operating Temperature Range:-20°C to +55°C

Humidity Range:5% to 95% RH, non-condensing

    The ABB SPDSM04 Pulse Input Module is designed to enhance precision in your industrial control systems. With 16 dedicated pulse input channels, it ensures reliable signal detection and processing, making it an indispensable component for applications where accuracy is paramount.

    Equipped with a high-speed sampling rate of up to 10 kHz, this module guarantees fast response times, crucial for dynamic processes that require immediate feedback. The robust power supply of DC 24V ensures stable operation under varying conditions.

    Operable within an extensive temperature range from -25°C to +70°C, the SPDSM04 is built to withstand harsh industrial environments, ensuring uninterrupted performance year-round.

    In terms of design, the compact size and lightweight construction (only 0.2kg) make it easy to integrate into existing systems without adding unnecessary bulk. Its dimensions of 76mm x 100mm x 100mm allow for efficient space utilization on control panels.

    For installation, the SPDSM04 is compatible with various ABB PLC series, simplifying integration processes. It is also compatible with standard industrial interfaces, further enhancing its versatility across different automation platforms.
