Protocol:DeviceNet

Board Type:Digital Input/Output

Connector Type:24-pin

Operating Voltage:DC 24V

Current Rating:500mA per channel

Communication Speed:125 kbps

Input Type:Non-isolated digital inputs

Output Type:Non-latching digital outputs

Number of Inputs:16

Number of Outputs:16

Dimensions:104mm x 94mm x 35mm

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

IP Protection Class:IP20

    The ABB DSQC697 DeviceNet Board, a critical component in industrial automation networks, offers unparalleled reliability and efficiency. Designed with advanced technology, it ensures robust connectivity and data transmission capabilities, making it an indispensable part of modern factory environments.

    This modular board supports a wide range of applications across diverse industries, including manufacturing, packaging, and process control. Its compact size facilitates easy installation, while its compatibility with ABB's extensive range of DeviceNet products ensures seamless integration with existing systems.

    Operational in extreme temperature conditions from -25°C to +70°C, the DSQC697 is built to withstand harsh industrial environments. Its low power consumption and high-speed bus interface (1 Mbps) make it energy-efficient and responsive, ideal for continuous operation in production lines.

    With a memory capacity of 64Kbit EEPROM, the DSQC697 provides ample storage for device configuration and data handling. Its high number of inputs and outputs (16 each) enables complex system configurations, allowing for versatile control over machinery and processes.

    For businesses seeking to enhance their automation capabilities, the ABB DSQC697 DeviceNet Board, model 3HAC037084-001, is the solution to streamline operations, improve productivity, and achieve greater efficiency in their manufacturing processes.
