Material:High-grade copper alloy

Operating Temperature Range:-20°C to +85°C

Input Voltage Range:220 V AC

Output Power Rating:10 kW

Size (LxWxH):200mm x 100mm x 30mm

Certification:CE, UL, TÜV

Connection Type:Terminal block with screw connections

    Engineered with precision, the ABB 3BHE028761R0101 GDC806A102 Drive Crowbar Circuit Board is a robust solution for protecting your industrial drive systems. Its compact yet durable design ensures it can withstand harsh industrial environments, offering reliable protection against transient overvoltages.

    Crafted from high-grade copper alloy, this circuit board provides exceptional conductivity and durability, guaranteeing long-lasting performance even under extreme conditions. The precise dimensions allow for seamless integration into various industrial setups.

    Equipped with advanced insulation technology, the board boasts an impressive insulation resistance of ≥10MΩ at 500V DC, ensuring it can handle high voltage applications without compromising safety or reliability.

    With a current capacity of up to 500A, it is capable of handling substantial electrical loads while maintaining its protective function effectively. The 50Hz operating frequency aligns perfectly with most industrial drive systems, making it a versatile addition to your equipment.

    The IP54 protection level ensures dustproof and splash-proof performance, making it suitable for outdoor and dusty industrial settings. Coupled with CE, UL, and CSA certifications, you can trust that this circuit board meets the highest safety standards.
