Power Rating:225 kW

Switching Frequency:Up to 12 kHz

Cooling Method:Air Cooled

Operating Temperature Range:-40°C to +70°C

Package Size:400x100x70mm

Insulation Class:F (155°C)

Control Interface:RS485 Modbus-RTU

    The ABB FS225R12KE3/AGDR-71C IGBT Module is engineered to meet the stringent requirements of today’s demanding industrial automation environments. It leverages ABB’s advanced semiconductor technology to deliver exceptional performance and reliability, making it an ideal choice for complex industrial control systems.

    Featuring a robust design with enhanced thermal management capabilities, this IGBT module ensures stable operation even under extreme conditions. Its high-efficiency switching characteristics significantly reduce energy consumption, contributing to sustainable industrial operations.

    The module is compatible with a wide array of control systems, facilitating seamless integration into existing industrial infrastructure. Its compact size and rugged construction enable efficient space utilization and robust durability, essential for long-term reliability in industrial settings.

    With its high current rating and high-frequency switching capabilities, the ABB FS225R12KE3/AGDR-71C IGBT Module is capable of handling heavy-duty applications with ease. It supports precise control over motors, drives, and other critical components, enhancing overall system performance and efficiency.

    Designed with safety in mind, this IGBT module complies with international safety standards and guidelines. Its built-in protection features safeguard against common failure modes, ensuring the continuous operation of industrial systems without interruption.
