ABB UNITROL 1020-0006 FULL 3BHE030579R0006 | Automatic Voltage Regulator (AVR)

Short Description:

ABB UNITROL 1020-0006 FULL (Order No. 3BHE030579R0006) is a fully-featured, comp

Send email to us

Product Detail

ABB UNITROL 1020-0006 FULL (Order No. 3BHE030579R0006) is a fully-featured, compact Automatic Voltage Regulator (AVR) from the UNITROL 1000 series. Designed for small-to-medium synchronous generators (up to 50MW), it delivers precise excitation control, voltage stability, and grid compliance.

Key Specifications

Model: UNITROL 1020-0006 FULL
Order No.: 3BHE030579R0006
Type: Digital Automatic Voltage Regulator (AVR)
Excitation Output: Up to 20 ADC continuous
Control System: Dual-core (separate control & communication CPUs)
Supply Voltage: Wide-range AC/DC input (flexible configuration)
Communication: Ethernet, USB, RS-232, Profibus DP
User Interface: Local HMI (LCD + keypad)
Dimensions (L×W×H): 245 × 500 × 335 mm
Weight: Approx. 6.71 kg
Operating Temp: -25°C to +70°C
Certifications: CE, UL, DNV, EMC compliant

Main Features

FULL Version Functionality: Complete set of control & protection features
Precise Voltage Regulation: PID-based AVR with fast dynamic response
Grid Code Compliance: Built-in Power System Stabilizer (PSS)
Auto Synchronization: For seamless generator paralleling
Power Factor & Reactive Power Control
Soft Start: Limits excitation inrush current
Dual-Channel & Redundancy Support
Advanced Load Sharing: For parallel generator operation
Rotating Diode Monitoring
Comprehensive I/O: Configurable analog/digital I/Os
Data Logging: Event & fault history recording
PC Tool: CMT1000 software for setup, diagnostics & simulation

Typical Applications

Diesel & gas generator power plants
Hydro & steam turbine power generation
Marine auxiliary & propulsion systems
Industrial co-generation & CHP plants
Data centers & critical backup power
Oil & gas, mining, manufacturing facilities
Wind turbines (direct-drive synchronous generators)
