3500/20 125760-01 Bently Nevada TMR RIM Rear I/O Termination Module Original In Stock

Short Description:

Dedicated rear I/O card matched with TMR triple redundant version 3500/20 front

Send email to us

Product Detail

Dedicated rear I/O card matched with TMR triple redundant version 3500/20 front rack interface module, supports Hiway bus & multi serial communication, realizes rack voting logic signal output and external system docking, exclusive for API670 TMR safety redundant TSI protection racks, tested surplus spare parts

Product Overview

PN：3500/20，Part No：125760-01
Brand：Bently Nevada (Baker Hughes)
Series：3500 Machinery Protection TSI System
Type：TMR Triple Redundant RIM Rear Termination I/O Module
Function：Exclusive rear wiring board paired one-to-one with TMR redundant type 3500/20 front RIM module (differentiated from ordinary 125768-01 standard rear card). It provides Data Hiway gateway interface, RS232/RS422 serial ports, rack global system relay contacts, alarm inhibit & reset terminals. Besides basic rack configuration and TDXnet transient data transmission, it undertakes triple-channel monitoring signal comparison voting logic signal output for TMR safety architecture, connecting Tricon/ Honeywell DCS control systems via Hiway protocol, and uniformly uploads all rack measurement data, fault logs and voting results to upper control platform.

Crucially, the RIM module does not participate in the hardwired trip interlock of vibration/overspeed protection channels; even if communication fails, each monitor module still executes local alarm and trip protection independently to guarantee unit safety

Core Features

Built-in Data Hiway dedicated communication interface, compatible with Honeywell TDC3000/2000, Tricon safety controller gateway access
Dual RS232+RS422 serial channels, supports Bently proprietary protocol, TDXnet waveform acquisition unit and local laptop configuration
Multiple groups of isolated dry contact outputs: rack system OK status, global alarm suppression, remote rack reset, trip amplification signal
Special circuit for TMR triple redundant data comparison transmission, matches front RIM to complete 2-out-of-3 voting judgment for redundant monitor channels
EMI filtering and surge protection circuit, stable signal transmission in strong electromagnetic interference power plant and petrochemical control rooms
Hot-swappable installation in Slot 1 (power supply adjacent slot) of 3500 rack; redundant power supply allows online replacement without rack shutdown

Technical Specifications

Communication Interfaces：Data Hiway, RS232, RS422
Baud Rate Max：38400 bps
Relay Contact Rating：5A@240VAC / 5A@30VDC
Typical Power Consumption：4.75W
Operating Temperature：-40℃ ~ +85℃
Net Weight：0.41kg
HS Code：8538900000
Certifications：CE, SIL2
Product Status：Discontinued, brand new original & fully tested surplus stock available

Compatibility

Mandatory Matching Front Module：TMR redundant version 3500/20 RIM front card (cannot pair with ordinary non-TMR 125744-02 front board)
Fixed Installation Position：Slot 1 (the first slot next to dual power supply slots) of all 3500/05 12-slot & 14-slot racks
Applicable Upper Equipment：TDXnet transient data processor, System 1 diagnosis platform, Honeywell DCS, Tricon SIS safety system
Not Compatible：Standard rear I/O card 125768-01, 3500/22M TDI module, non-3500 series third-party rack chassis

Application

TMR triple redundant safety architecture construction for steam turbine, gas turbine and large centrifugal compressor 3500 TSI protection racks
Rack parameter downloading, historical event query and startup/coastdown vibration waveform data extraction via TDXnet equipment
Interconnection between 3500 monitoring rack and factory main DCS/SIS safety interlock system through Data Hiway bus
Spare replacement and system upgrade transformation of legacy high-reliability redundant turbomachinery protection monitoring frames
