BENTLY 350022M 138607-01V TDI transient data interface module for 3500 machinery protection system, gateway for System 1 software, collects static and transient waveform vibration data.

Product Overview

BENTLY 350022M 138607-01V is the Transient Data Interface (TDI) module for Bently Nevada 3500 series machinery protection system. It combines rack interface and data acquisition functions, acting as the communication gateway between the 3500 rack and System 1 condition monitoring software. It collects steady-state and transient waveform data from monitoring modules and uploads data via Ethernet for equipment vibration analysis and fault diagnosis.

Key Features

• Integrates rack interface module and transient data acquisition processor
• 10/100 Base-T Ethernet port for connection to System 1 software
• Front USB port for local rack configuration and parameter setup
• Static data capture by default, dynamic transient data supported with optional enable disk
• Occupies slot 1 next to power supply inside the 3500 rack
• With key lock function to prevent unauthorized configuration modification

• Compliant with API 670 machinery protection standard

•


Technical Specifications

• Model: 350022M (3500/22M)
• Part No: 138607-01V
• Type: Transient Data Interface (TDI)
• Compatible Series: Bently Nevada 3500 TSI system
• Communication: 10/100 Ethernet, USB
• Installation Slot: Slot 1 beside power supply

• Function: Data gateway, rack configuration, transient waveform collection

•


Application

Steam turbine, compressor, pump and other rotating machinery condition monitoring, vibration protection, fault diagnosis in power, oil & gas, chemical and metallurgy industries.
