Front VGA display interface card for 3500 machinery protection rack, pairs with rear I/O card 147663-01, connects industrial touch screen to view real-time vibration, speed, alarm data locally without upper computer, surplus tested spare parts for turbomachinery monitoring system

Product Overview

• PN：3500/94，Part No：145988-01
• Brand：Bently Nevada (Baker Hughes)
• Series：3500 Machinery Protection TSI System
• Type：VGA Display Front Module

• Function：Full-height front human-machine interface module inserted into 3500 rack slot, must be matched one-to-one with dedicated rear I/O termination board 147663-01. It collects all channel measurement values, equipment running status, alert/danger alarms and historical fault logs from every monitoring module inside the rack, transmits signals via rear card to external industrial touch VGA monitor. On-site operators can directly check shaft vibration, axial thrust, differential expansion, overspeed, bearing temperature and system fault records through touch operation, and support editing up to 9 groups of custom monitoring display pages classified by unit equipment.

•


Core Features

1. Real-time synchronous reading of full rack bus data, alarm information marked with color prompt for quick fault positioning
2. Matched rear card reserves standard VGA + RS232 serial port, the touch screen can be installed up to 8 meters away from the rack with standard cable connection
3. Supports rack overall system view, single channel detailed data browsing, alarm event history query and export
4. Front panel LED indicator to show module power supply, communication link and operating fault status
5. Hot-swappable plug-in design; replaceable without powering off the entire rack under redundant power configuration

6. Basic language and display parameter configuration can be finished via official 3500 rack configuration software before commissioning

7.


Technical Specifications

• Form Factor：Full-height single-width front module for 3500 rack
• Power Supply：22.5~25.5VDC powered by rack backplane
• Max Power Consumption：4.6W
• Maximum Transmission Distance：8m (25ft) standard cable; longer distance extension via KVM fiber extender
• Operating Temperature：-40℃ ~ +70℃
• Net Weight：0.73kg
• HS Code：8538900000
• Certification：CE

• Product Status：Manufacturer discontinued, brand new original & refurbished tested spare parts in stock

•


Compatibility

• Mandatory Matching Rear I/O Card：147663-01
• Applicable Rack：All 3500/05 series 12-slot & 14-slot panel mount monitoring chassis
• Matching Peripheral：10-inch / 15-inch industrial touch VGA dedicated display screen for 3500 system
• Supporting Software：3500 rack configuration software, System 1 equipment condition monitoring platform

• Incompatible Items：3500/94M upgraded version display module, other model rear termination cards, non-3500 series third-party racks

•


Application

1. Local on-site monitoring and operation terminal for steam turbine, gas turbine and centrifugal compressor 3500 TSI protection racks in thermal power, petrochemical and refining industries
2. Real-time checking of unit protection parameters and alarm records without connecting laptop or central control DCS
3. Local HMI visualization transformation and spare module replacement of old 3500 machinery protection monitoring systems
