3500/20 125744-02 Bently Nevada Standard RIM Rack Interface Front Module Original In Stock

Short Description:

Essential front rack interface card installed in Slot 1 of 3500 TSI rack, paired

Send email to us

Product Detail

Essential front rack interface card installed in Slot 1 of 3500 TSI rack, paired with rear I/O module 125768-01 for rack configuration, serial communication and system status management. Protection trip logic remains intact if the module malfunctions, fully tested surplus spare parts for turbomachinery monitoring systems

Product Overview

PN: 3500/20, Part No: 125744-02
Brand: Bently Nevada (Baker Hughes)
Series: 3500 Machinery Protection TSI System
Type: Standard Non-TMR Rack Interface Module Front Card
Function: This module must be fitted into Slot 1 adjacent to the dual power supply slots of every 3500 rack, with one unit required per rack. Serving as the core communication hub of the entire chassis, it retrieves data from all vibration, overspeed, relay and communication modules via the rack backplane bus. It enables parameter downloading, real-time data reading, alarm record retrieval and system event log access through official configuration software. It supports connection with TDXnet transient data processors for waveform capture and links upper-level monitoring hosts via serial protocols.This module does not belong to the safety protection loop. Even when the RIM is faulty or removed, all monitoring modules will still execute local alert and danger alarm outputs as well as hardwired trip signals without interfering with unit safety interlock.

Core Features

Standard RIM edition without TMR triple redundant channel comparison function; dedicated TMR front cards are required for use with 125760-01 rear I/O module
Front panel key lock switch to avoid unauthorized modification of rack configuration parameters
LED indicators display power supply status, rack bus communication, module faults and global system alarm status
Hot-swappable structure allowing online replacement without rack power cut under redundant power supply setup
Compatible with Bently proprietary communication protocols and external data acquisition devices including TDXnet, TDIX and DDIX
Collects rack self-test data and module fault codes to facilitate troubleshooting and predictive maintenance

Technical Specifications

Typical Power Consumption: 4.75 W
Maximum Serial Baud Rate: 38400 bps
Maximum Local Serial Connection Cable Length: 2.1 m (7 ft)
Operating Temperature Range: -40℃ ~ +85℃
Net Weight: 0.45 kg
HS Code: 8538900000
Certifications: CE
Product Status: Discontinued by original manufacturer; brand new original units and fully tested refurbished surplus items available

Compatibility

Mandatory Matched Rear I/O Module: 125768-01 standard RS232/RS422 termination card
Fixed Mounting Slot: Slot 1 of all 3500/05 12-slot and 14-slot panel mount racks
Supported Software: 3500 rack configuration software, System 1 condition monitoring platform
Incompatible Products: TMR RIM rear card 125760-01, 3500/22M TDI module, third-party non-3500 series rack chassis

Application

Parameter configuration and on-site commissioning of 3500 protection racks for steam turbines, gas turbines and compressors in power generation and petrochemical industries
Transmission of steady-state monitoring data and historical fault logs to DCS and monitoring systems in central control rooms
Connection with TDXnet equipment to capture transient vibration waveforms during unit startup and coastdown for rotor fault diagnosis
Spare part replacement and maintenance upgrading of legacy 3500 machinery protection monitoring racks
