Product Overview

• Part Number: GVC736CE101, full order code 3BHE039203R0101
• Brand: ABB
• Type: All-in-one thyristor trigger power assembly (thyristor + drive trigger board integrated)

• FunctionCore power switching component for generator UNITROL excitation rectifier cabinets and ACS6000 medium voltage inverters. It receives optical trigger signals from main control boards to complete AC-DC rectification. It adjusts excitation current of generators and output voltage/frequency of medium voltage drives. Built-in signal conditioning, fault detection and overcurrent protection circuits monitor thyristor working status in real time, cutting off pulses when abnormalities occur to protect power devices. Double-sided water cooling structure dissipates heat efficiently for stable heavy-load operation.

•


Core Features

1. Integrated design: Press-pack thyristor power chip + dedicated trigger circuit board combined as one unit, convenient overall replacement
2. Optical fiber trigger mode completely isolates high voltage and control signals, strong anti-interference in power plant high-voltage cabinets
3. Double-sided cooling reserved water pipe interface, supports water cooling and forced air cooling, suitable for long-time heavy current operation
4. Conformal coated circuit board, dust-proof, moisture-proof and anti-corrosion, adapts harsh power, chemical and metallurgy environments
5. Onboard fault indicator lights, quickly locate trigger failure, thyristor breakdown and cooling anomalies

6. Fixed standardized installation size, matched dedicated clamping installation tool

7.


Technical Specifications

• Matching thyristor rated voltage: 4500V
• Rated average through current: 2500A~3000A
• Trigger mode: Fiber optic optical signal triggering
• Cooling mode: Water cooling preferred, air cooling optional
• Operating junction temperature: -40℃ ~ +125℃
• Operating ambient temperature: -20℃ ~ +70℃
• Net weight: 1.26kg
• Protection Grade: IP20 (cabinet internal installation only)
• HS Code: 85413090

• Supply: Brand new original, new old stock and fully tested refurbished assemblies available

•


Compatibility

• Applicable equipment: ABB UNITROL series generator excitation systems, ACS6000 medium voltage frequency converters
• Supporting accessories: Optical fiber trigger lines, cooling water pipes, installation clamping fixtures
• Applicable industries: Thermal power, hydropower, metallurgical mines, petrochemical high-power drive workshops

• Strict one-to-one replacement; cannot be replaced by other GVC series modules

•


Application

• Overall replacement for damaged integrated thyristor drive components in excitation rectifier bridges
• Maintenance overhaul of power units of ACS6000 medium voltage inverters
• Troubleshooting excitation failure, inverter rectifier fault and trigger loss alarms
• Long-term standby spare parts for power station excitation cabinets and medium voltage drive power stacks
