Product Overview

• Part No: RK682011-BA
• Brand: ABB

• Category: Industrial I/O UnitRK682011-BA is a standard rack-mounted I/O unit for ABB industrial automation control systems. It acts as the signal interface between the main controller and field-side sensors and actuators. The module collects digital and analog feedback signals from on-site equipment, transmits data to the central controller, and receives control commands to drive field devices. It realizes real-time signal exchange to support equipment status monitoring, logic interlock and automatic process regulation, which is an essential spare component for system maintenance and upgrade.

•


Core Features

• Integrated multi-channel signal input and output circuit, supporting collection and output of common industrial standard signals
• Built-in channel isolation design, effectively suppress electromagnetic interference inside industrial control cabinets
• On-board status indicator lights for intuitive channel diagnosis and quick fault location
• Standard subrack plug-in structure, easy installation, disassembly and direct replacement
• Flexible software parameter configuration to adapt to diverse process control requirements

• Strict industrial aging testing, supporting stable continuous long-cycle operation

•


Technical Specifications

• Rated Power Supply: 24VDC
• Installation Method: Standard rack slot mounting
• Operating Temperature: -20°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C

• Protection Class: IP20, indoor control cabinet installation

•


Compatibility & Application

• Compatible with matched ABB automation controller series and system backplanes
• Widely used in power industry, metallurgy, chemical, pulp and paper, water treatment and manufacturing automation projects
• Applied for valve feedback monitoring, equipment running signal collection, safety interlock and actuator drive control
