Product Overview

• Part No: 5SHX10H6004
• Brand: ABB

• Category: IGCT Power Semiconductor Module5SHX10H6004 is a high-performance integrated gate-commutated thyristor (IGCT) manufactured by ABB. It serves as the core power switching component in medium voltage power conversion systems. The device undertakes high-power energy switching tasks, cooperates with drive boards to complete rectification and inversion processes. With fast switching speed and low on-state loss, it can withstand high voltage and large current operating conditions, and is widely used as a key replacement component for maintenance of industrial medium voltage power equipment.

•


Core Features

• Excellent high voltage and high current bearing capacity, suitable for medium voltage power conversion occasions
• Fast switching characteristics, low conduction loss, improving overall system energy efficiency
• Integrated compact structure, convenient installation and heat sink assembly
• Stable performance under frequent switching and variable load operation
• High reliability design, passed rigorous industrial power cycle testing

• Standard interface matching supporting ABB dedicated gate drive units

•


Technical Specifications

• Device Type: IGCT
• Operating Temperature: -40°C ~ +125°C
• Storage Temperature: -40°C ~ +125°C
• Installation: Mounted on dedicated cooling heat sink

• Application Environment: Inside medium voltage power cabinet

•


Compatibility & Application

• Matched with ABB medium voltage inverters, static var compensators and high-power rectifier units
• Widely applied in power plant auxiliary drive, metallurgical transmission, mine medium voltage drive and power quality control projects
