Product Overview

• Part No: 5SGX10H6004
• Brand: ABB

• Category: Reverse Conducting IGCT Power Module5SGX10H6004 is ABB high-performance reverse conducting Integrated Gate-Commutated Thyristor (RC-IGCT). It integrates freewheeling diode inside the device, serving as the core high-power switching component for medium voltage power electronic systems. Cooperated with matched gate drive boards, it realizes rectification, inversion and reactive power compensation. This module features compact structure, low conduction loss and outstanding short-circuit withstand capability. It is an essential spare component for overhaul of medium voltage inverters, static var compensators and generator excitation power units.

•


Core Features

• Built-in integrated freewheeling diode, simplifies power stack mechanical design
• High voltage and large current rating, suitable for megawatt-level medium voltage power conversion
• Fast switching performance, low on-state power loss, improves overall system efficiency
• Robust short-circuit protection characteristic, enhance equipment operational safety
• Optimized flat-pack mechanical form, convenient assembly on dedicated cooling heat sink
• Strict power cycle and thermal aging testing, reliable under continuous dynamic load

• Standard interface compatible with ABB series gate drive boards

•


Technical Specifications

• Device Type: Reverse Conducting IGCT (RC-IGCT)
• Junction Operating Temperature: -40°C ~ +125°C
• Storage Temperature: -40°C ~ +125°C
• Installation: Mounted on professional liquid/air cooling heat sink

• Working Environment: Installed inside sealed medium voltage power cabinet

•


Compatibility & Application

• Matched with ABB medium voltage variable frequency drives, static var compensators and high-power rectifier systems
• Widely applied in power plant auxiliary drives, metallurgical medium voltage transmission, mining converters and grid power quality regulation projects
