Board Type:High Voltage Pulse Amplifier

Function:Interface Control to Power Bridge

Discontinued Status:No, still supported and updated

Function Acronym:HVPA

Instruction Manual:GEI-100461

Model Number:IS200EHPAG1AFD

Notable Components:On-board LED indicators for operational status

OEM/Manufacturer:General Electric, GE Industrial Systems

Weight:Approximately 1.4 lbs

    The IS200EHPAG1AFD is a critical component in turbine control systems, ensuring precise voltage regulation for optimal performance.

    Its programmability allows for customization to meet specific operational needs, making it versatile for various applications in power generation.

    Equipped with multiple transformers, the unit provides robust power amplification capabilities, crucial for maintaining system reliability under varying load conditions.

    Supporting both simplex and redundant modes ensures system availability and fault tolerance, enhancing overall operational safety.

    The integration of ten or more resistors contributes to accurate current control, optimizing efficiency and reducing energy loss in the turbine system.

    Designed by General Electric, a leading manufacturer in industrial systems, the IS200EHPAG1AFD is built to withstand demanding industrial environments, ensuring long-term reliability.
