GE VMIACC-5595-208 350-805595-208N is a 2Gb/s reflective memory hub assembly for GE 5565 reflective memory network, with 8 SFP fiber ports, automatic node bypass, ultra-low latency real-time data sharing.

Product Overview:

GE VMIACC-5595-208 350-805595-208N is a high-performance reflective memory hub assembly, designed to match the GE 5565 series reflective memory modules. It realizes deterministic, low-latency real-time memory sharing among multiple nodes over fiber links. This 1U rack-mount hub supports cascading, remote network management, and automatic fault bypass to guarantee continuous real-time communication for high-speed control systems.

Key Features:

• 2 Gb/s high-speed reflective memory network transmission
• 8 SFP fiber ports, compatible with single-mode / multi-mode transceivers
• Automatic bypass for disconnected or faulty nodes, avoid network interruption
• Each port regenerates optical signals, reduce jitter and signal attenuation
• Max up to 256 network nodes via cascading
• Built-in 10Base-T Ethernet and RS232 port for local & remote configuration
• 19-inch 1U rack mounting, metal housing for industrial use

• Deterministic real-time data synchronization, ideal for high-speed control

•


Technical Specifications:

• Brand: GE
• Model: VMIACC-5595-208
• Part No: 350-805595-208N
• Data Rate: 2 Gb/s
• Fiber Ports: 8 × SFP slots
• Management Port: 1 × 10Base-T RJ45, 1 × RS232
• Mounting: 1U rack mount
• Max Nodes: 256
• Max Fiber Distance: up to 10km

• Compatible Series: 5565 reflective memory modules

•


Compatibility & Application:

It is widely applied in simulation systems, turbine control, aerospace test platforms, high-speed motion control, nuclear power and real-time industrial simulation, compatible with GE VMIC reflective memory network modules.
