Manufactured by:General Electric

Model Number:DS3800NAIB1

Function:Reduces power consumption through dynamic voltage and frequency scaling

Number of Integrated Circuits:Five

Marking:6BAD5 and A-J, top edge

Connector Type:Two, male-female configuration

Board Fixation Points:Twelve screw mount locations

LED Count:Over thirty-five red LEDs

Connection Points:Nine for different wiring harnesses

    The GE DS3800NAIB1 is a critical component in the Speedtronic Mark IV system, engineered to optimize performance and energy management in turbine operations.

    With its dynamic voltage and frequency scaling capabilities, this multi-volt buffer significantly reduces power consumption without compromising operational efficiency.

    Featuring five integrated circuits, the DS3800NAIB1 offers unparalleled reliability and compatibility within the Mark IV system architecture.

    Accompanied by over thirty-five red LEDs, the board provides clear status indicators, ensuring real-time monitoring and diagnostics.

    Equipped with a robust mounting system, the DS3800NAIB1 ensures secure installation, facilitating easy integration and maintenance.

    This product exemplifies General Electric's commitment to innovation and reliability in industrial control solutions, making it an indispensable asset in modern turbine control systems.
