Manufactured By:General Electric

Model Number:DS200TCEAG1AGB

Application:Turbine Control Systems

Revision Level:K-rated secondary functional revision

Artwork Configuration Revision:G-rated

Coating Style:Group one

Operating Temperature Range:-40°C to +85°C

Input Voltage Rating:120VAC or 230VAC

Output Relay Contacts:3 SPDT

Board Dimensions:240mm x 160mm

Weight:0.5kg

    The DS200TCEAG1AGB Emergency Overspeed Board is a vital component in ensuring the safety and reliability of turbine operations, specifically designed for General Electric's Mark V Series of turbine control systems.

    It features a robust design capable of handling extreme conditions, ensuring optimal performance under various operational pressures.

    Equipped with advanced signal connectors (JK TCEB, JL TCTG, JW TCEB, JX1 and JX2), it seamlessly integrates into the existing system architecture, providing enhanced monitoring and control capabilities.

    The board's J7 PD Core Power Distribution Connector ensures efficient power distribution, safeguarding against potential electrical hazards.

    Manufactured with precision-engineered components, this board adheres to strict quality standards, offering unparalleled reliability and longevity.

    For users seeking to maintain or upgrade their turbine control systems, the DS200TCEAG1AGB Emergency Overspeed Board represents an essential investment in safety and operational efficiency.
