Power Supply:24VDC

Input/Output Channels:16 channels

Communication Protocol:Modbus RTU

Environmental Rating:IP20

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +70°C

Dimensions:60mm x 40mm x 30mm

Weight:100g

    The AB 1769-ECL Compact I/O End Module is engineered to provide precise control over industrial processes, ensuring smoother operations and reduced downtime. Its compact size and versatile mounting options make it ideal for space-constrained environments, while its robust design withstands harsh industrial conditions.

    With support for Modbus-RTU protocol, this module seamlessly integrates with a wide range of Allen-Bradley controllers, facilitating easy communication and data exchange within the automation network. It offers high-speed response times and reliable signal processing, critical for real-time monitoring and control applications.

    Featuring a broad operating temperature range and IP20 enclosure, the 1769-ECL is suitable for various industrial settings, from cold storage facilities to hot manufacturing plants. Its terminal block connections allow for quick and secure wiring, minimizing installation time and effort.

    This module supports both digital and analog inputs and outputs, enabling precise control over actuators, sensors, and other equipment. With its load rating and extensive channel capacity, it can handle a wide variety of load types and sizes, making it a versatile choice for numerous industrial applications.

    Equipped with advanced diagnostics and fault reporting capabilities, the AB 1769-ECL ensures continuous operation by promptly alerting operators to any potential issues. Its integration with Allen-Bradley's comprehensive ecosystem of automation products further enhances system performance and maintenance efficiency.
