Brand:Allen-Bradley / Rockwell Automation

Model:1786-TPR

Application:ControlNet, Coaxial

Connection Type:T-Tap, Right Angle

Cable Length:1 Meter

Connector Type:BNC

Environmental Rating:IP20

Material:Metal

Operating Temperature:-40°C to 70°C

Operating Humidity:0% to 95% non-condensing

    The Allen-Bradley 1786-TPR cable connector is designed for seamless integration with ControlNet networks in industrial automation environments. Its right angle T-Tap design optimizes space usage on control panels, ensuring a clean and organized layout.

    Featuring a flexible terminal base with a total of 32 I/O terminals, 8 common terminals, and 8 + voltage terminals, this connector provides comprehensive connectivity options suitable for various industrial applications. The screw-clamp mounting style ensures a secure fit without compromising on ease of installation.

    Equipped with a 1-meter long BNC cable, the 1786-TPR guarantees reliable data transmission over moderate distances, making it an ideal choice for industrial settings where signal integrity is crucial.

    With its open-style design, the connector offers quick and easy access to individual terminals, facilitating maintenance and troubleshooting. The DIN mount compatibility ensures straightforward installation on standard industrial equipment.

    Designed to withstand harsh industrial conditions, the 1786-TPR cable connector meets IP20 protection standards, safeguarding against dust and splashing water. This makes it suitable for use in a wide range of industrial environments.
