Model Type:Diagnostic AC Output Module

Model Number:1756-OA8D

Manufacturer:Allen-Bradley

Output Channels:8

Output Type:AC

Isolation Rating:30VDC

Current Rating:10A at 24VDC

Operating Temperature:-40°C to +70°C

Enclosure Type:IP20

Communication Interface:ControlLogix Compatible

Power Consumption:2W (Typical)

    The AB 1756-OA8D is engineered to integrate seamlessly with ControlLogix systems, providing critical diagnostics for efficient operation and maintenance. It features high-speed switching and robust isolation capabilities, ensuring reliable performance in harsh industrial environments.

    Each channel supports independent output control, enabling precise monitoring and adjustment of AC loads. This makes it ideal for applications requiring detailed system analysis and proactive troubleshooting.

    The module is housed in an IP20 enclosure, offering protection against dust and splashes of water, suitable for various industrial settings. Its compact design allows for easy integration without compromising functionality.

    With a wide operating temperature range from -40°C to +70°C, this module is designed to withstand extreme conditions, making it suitable for deployment in diverse global markets.

    Comprehensive documentation and support are provided to facilitate quick installation and setup, minimizing downtime and maximizing productivity.
