Manufacturer:Allen-Bradley

Model Number:1794-IB8

Series:CompactLogix

Module Type:Digital Input

Channels:8

Rating:24V DC

Current Load:Up to 500mA per channel

Connection Type:Terminal Block

Operating Temperature:-10°C to +60°C

Storage Temperature:-40°C to +85°C

Dimensions:106mm x 116mm x 100mm

Weight:0.3kg

Communication Interface:EtherNet/IP

Protocol Support:Modbus TCP/IP

    The AB 1794-IB8 Input Module is a critical component in industrial automation systems, engineered to enhance operational efficiency and reliability. It features an advanced digital input mechanism, capable of processing up to eight inputs simultaneously, which are essential for monitoring and controlling various industrial processes.

    Equipped with dual-pole double-throw (DPDT) switches and single-throw configurations, this module offers unparalleled flexibility in signal interpretation, allowing precise control over machinery and equipment. Its modular design facilitates easy integration and customization to fit diverse application requirements.

    Featuring an RS-485 communication interface, the AB 1794-IB8 ensures reliable data transfer between the module and other components in the system, enhancing the overall network stability. The compact dimensions (96 x 100 x 105 mm) and lightweight construction (0.3kg) make it suitable for installation in various industrial settings without compromising on performance.

    Operated within a wide temperature range from -10°C to +60°C, this module ensures consistent performance under varying environmental conditions. For storage, it can withstand temperatures ranging from -40°C to +85°C, ensuring durability and longevity in challenging environments.

    Designed with an IP20 enclosure type, the AB 1794-IB8 Input Module provides adequate protection against dust and splashes, making it ideal for use in manufacturing plants and other industrial environments where maintenance and safety are paramount. The panel-mount feature simplifies installation, saving valuable space in the control cabinet.
