Product Type:Analog Current Output Module

Model Number:1746SC-NO8I

Manufacturer:Allen Bradley

Number of Channels:8

Output Range:0 – 21.5 MA

Operating Voltage:24 VDC ± 10%

Minimum Output Current:300 MA

Current Output Ranges:4 – 20 MA, 0 – 20 MA, 0 – 21 MA, 0 – 21.5 MA

Current Rating:Backplane: 120 MA at 5 VDC, 250 MA at 24 VDC (J4 Jumper Set To Rack), 0 MA at 24 VDC (J4 Jumper Set To EXT)

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Display:Status LED

Connection Cables:24 – 14 AWG

Mounting:Chassis

    The Allen Bradley 1746SC-NO8I Output Module is meticulously engineered for seamless integration into complex industrial automation systems, ensuring consistent performance under demanding conditions.

    This high-performance digital output module is characterized by its robust design and enhanced durability, making it suitable for a wide range of industrial environments.

    With an extensive output range and adjustable current capabilities, the 1746SC-NO8I allows for precise control over various actuators and devices, optimizing production processes for efficiency and accuracy.

    Featuring a status LED display, users can easily monitor the operational status of each channel, facilitating quick troubleshooting and maintenance.

    The open type enclosure ensures easy accessibility for installation and maintenance, while the compatibility with standard connection cables simplifies the integration process.

    Designed with flexibility in mind, the Allen Bradley 1746SC-NO8I Output Module supports a variety of configurations, enhancing its adaptability to diverse industrial applications.
