Extended Product Type:Other

Product ID:X20BT9400

B&R Type Designation:Other

Link bus transmitter:Yes

System Compatibility:Up to 100 m segment lengths

Internal I/O Supply:Feed for internal I/O

X2X Link Supply:Integrated for the X67 system

Operation Slot:Only on the slot to the far right

Power Consumption (Bus):0.5 W

Input Voltage:24 VDC -15% / +20%

Input Current:Max. 0.5 A

Nominal Output Voltage:24 VDC

Permissible Contact Load:10 A

    The B&R X20BT9400 Bus Transmitter Module is a versatile component that seamlessly integrates with various industrial control systems, ensuring reliable data transmission across long distances. Its compact design and built-in power supply for internal I/O make it an ideal solution for optimizing system architecture.

    With its robust X2X Link functionality, this module supports the expansion of your system up to 100 meters, making it suitable for applications where long-distance communication is required without compromising on performance or reliability.

    Featuring an integrated power supply for the X67 system, the B&R X20BT9400 ensures efficient operation and reduces installation complexity, allowing you to focus on more critical aspects of your project.

    Designed with precision and durability in mind, this module operates exclusively on the rightmost slot, providing optimal space utilization within your existing control panel setup. This strategic placement ensures minimal interference and maintains system integrity.

    Equipped with a low power consumption rating of 0.5W, the B&R X20BT9400 is energy-efficient, reducing operational costs and environmental impact. Its compatibility with 24VDC power sources (-15% / +20%) ensures wide-ranging application flexibility.

    With a nominal output voltage of 24VDC and a permissible contact load of 10A, the B&R X20BT9400 Bus Transmitter Module offers robust connectivity and high reliability. It's a smart choice for enhancing the efficiency and scalability of your industrial automation projects.
