Type:Temperature Input Module

Model Number:1C31164G02

Module Category:Ovation Series

Operating Voltage:24V DC

Input Range:-200°C to +850°C

Resolution:0.01°C

Accuracy:±0.2% of measured value

Communication Interface:MODBUS RTU

Power Consumption:≤1.5W

Protection Rating:IP20

Operating Temperature:-10°C to +55°C

Storage Temperature:-20°C to +70°C

    Integrating cutting-edge technology, the WESTINGHOUSE 1C31164G02 Ovation RTD Input Module is engineered to enhance the accuracy and reliability of industrial temperature monitoring systems. It seamlessly connects with RTD sensors, offering precise measurements over a wide temperature range from -40°C to +85°C.

    With its compatibility with various RTD standards such as PT100, PT1000, CU50, and CU100, this module ensures compatibility with a broad spectrum of industrial applications. The high accuracy of ±0.01% + ±1 count ensures dependable temperature readings, critical for process control and safety in manufacturing environments.

    Featuring a compact yet robust design, the module is housed in a durable enclosure that withstands harsh industrial conditions. It consumes a low current of ≤50mA, making it energy-efficient and suitable for systems with stringent power requirements.

    Equipped with a 1 Form C SPDT relay, the module provides a reliable output for system alarms or control actions when specific temperature thresholds are met. This feature is essential for real-time monitoring and response to temperature changes in industrial processes.

    Installation and maintenance are straightforward with the WESTINGHOUSE 1C31164G02 Ovation RTD Input Module. Its modular design allows for easy integration into existing systems without requiring extensive customization. Backed by comprehensive documentation and technical support, users can rely on quick implementation and ongoing assistance.
