Model Type:DeviceNet Scanner Module

Scanner Module Model Number:1747-SDN

Manufacturer:Allen-Bradley

Amperage Rating (Backplane):5 VDC, 500 MA

Amperage Rating (DeviceNet):24 VDC, 90 MA

Mounting:Chassis

Communication Speed:125 KBPS

Length:1-23/64 IN

Width:5-1/8 IN

Height:5-11/16 IN

Enclosure:Open Type

Rfi Suppression (Radiated):10 V/M With 1 KHZ Sine-Wave 80% AM From 80 – 2000 MHZ

Rfi Suppression (Conducted):10 VRMS With 1 KHZ Sine-Wave 80% AM From 150 KHZ – 80 MHZ

Temperature Rating:32 – 140 DEG F

Environmental Conditions:Relative Humidity: 5 – 95%

    The Allen-Bradley AB 1747-SDN DeviceNet Scanner Module is engineered for robust performance in harsh industrial environments. This model excels in providing accurate and reliable data acquisition for various automation tasks.

    With an amperage rating of 500 mA for the backplane and 90 mA for DeviceNet, this module ensures efficient power distribution and communication capabilities.

    Featuring a compact size of 1-23/64 IN in length, 5-1/8 IN in width, and 5-11/16 IN in height, it seamlessly integrates into diverse chassis configurations without compromising on functionality.

    The open type enclosure design provides adequate ventilation while protecting against environmental hazards, ensuring the longevity and reliability of the module.

    Equipped with advanced RF interference suppression technology, this module can operate reliably in environments with electromagnetic disturbances, guaranteeing consistent performance.

    Ideal for applications requiring precise temperature control, the module's operational range from 32 to 140 degrees Fahrenheit ensures compatibility with a wide variety of industrial settings.
