Model Type:SLC500

Model Number:1746-NR4

Manufacturer:Allen-Bradley

Analog Input Channels:4

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)

Input Range:-10 To 10 VDC – 1 LSB

Absolute Input Current:-30 To 30 MA (Max.)

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 35 MA at 5 V, 85 MA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

    The AB 1746-NR4 is meticulously engineered for high-precision industrial control systems, ensuring reliability and accuracy in complex automation environments.

    This module supports a wide range of analog signals, making it suitable for integration into various control loops where fine-tuned output adjustments are critical.

    With its robust design and comprehensive feature set, the 1746-NR4 offers enhanced performance and flexibility, catering to the demands of modern manufacturing processes.

    Featuring a user-friendly interface and straightforward configuration options, the module simplifies setup and maintenance, enhancing operational efficiency.

    Equipped with advanced protection mechanisms, the AB 1746-NR4 safeguards against overvoltage and ensures stable operation in challenging industrial conditions, guaranteeing system uptime and productivity.
