Manufacturer:Allen-Bradley

Model Number:1746-IM8

Module Type:Analog Input Module

Input Channels:8

Operating Voltage:12 to 24 VDC

Current Consumption:Max. 100 mA per channel

Communication Protocol:ControlLogix Ethernet/IP

Dimensions:87 mm x 60 mm x 112 mm

Weight:0.3 kg

Environmental Conditions:Temperature range -40°C to +70°C, Humidity range 5% to 95% non-condensing

IP Rating:NEMA 1, IP20

Safety Certification:UL, CE

    Introducing the AB 1746-IM8 Analog Input Module, a critical component for enhancing the precision and reliability of your industrial automation systems. This module is specifically designed to interface with a wide range of sensors, enabling real-time monitoring and control of various environmental conditions and operational parameters.

    Featuring an expansive operating voltage range from 12 to 48V DC, the 1746-IM8 is robust enough to withstand harsh industrial environments. Its versatile input range supports either 0 to 10V or 4 to 20mA signals, ensuring compatibility with most sensor outputs.

    With 8 channels per module, you can easily expand your monitoring capabilities without the need for additional hardware. The RS-485 communication interface facilitates efficient data exchange between this module and your existing control system, ensuring smooth operation and reduced downtime.

    Crafted with high-quality materials, the AB 1746-IM8 is built for durability and longevity. Its compact size (2.6 x 5.7 x 1.2 inches) and lightweight design (0.4 lbs) make it easy to integrate into any industrial setup, minimizing space requirements and facilitating quick installation.

    Optimized for ease of use, the 1746-IM8 comes with comprehensive documentation and support, allowing for straightforward configuration and troubleshooting. Whether you're upgrading your existing system or building a new one, this module offers a cost-effective solution to enhance your automation capabilities.
