Operating Voltage:24V DC

Number of Channels:16

Counting Rate:Up to 100 MHz

Counter Modes:Flexible selection including normal, up/down, two's complement

Range of Counting Values:Up to 32 bits

Input Signals:25-pin D-sub connector with 24 inputs

Power Consumption:Maximum 1 W at 24V DC

Operating Temperature:-40°C to +70°C

Storage Temperature:-55°C to +85°C

    Engineered for high-precision performance, the AB 1746-HSCE High-Speed Counter Module from Allen Bradley is a critical component for applications requiring fast and accurate counting.

    Designed to handle a wide range of temperatures (-20°C to +70°C), this module ensures reliable operation in diverse industrial environments.

    With its ability to count at rates up to 1 MHz, it meets the stringent requirements of modern automation systems, enhancing efficiency and productivity.

    Featuring eight channels, the module offers flexibility in configuring multiple counting tasks within a single system, simplifying the integration process.

    The inclusion of RS-485, DeviceNet, and ControlNet compatibility ensures seamless communication with other Allen Bradley PLCs and devices, creating an interconnected and efficient industrial network.

    Manufactured with robust materials and advanced technology, the AB 1746-HSCE is built to withstand harsh conditions, providing a long-lasting solution for continuous operation.
