Model Type:SLC 500

Model Number:1746-OB16E

Number of Channels:16

Input Voltage:24 VDC

Output Voltage Range:10 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load:1 MA

Continuous Current Per Output:0.25 A at 60°C

Continuous Current Per Module:4 A at 60°C

Isolation:Communication Circuits: 500 VDC; Backplane: 1500 VAC

Processor:SLC 500

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% non-condensing relative humidity

Shock Resistance:30 G

    The Allen Bradley AB 1746-OB16E SLC 500 Digital DC Output Module is a critical component for industrial control systems, ensuring precise and reliable operation under extreme conditions.

    Featuring 16 digital output channels, this module supports versatile applications requiring high-level precision and efficiency. Its robust design allows for seamless integration into existing systems.

    With an operating voltage range of 10 – 50 VDC, the module offers flexible compatibility with various power sources, making it suitable for a wide range of industrial environments.

    Equipped with advanced isolation technology, the AB 1746-OB16E ensures reliable signal transmission without interference, enhancing system performance and stability.

    Designed for open-type enclosures and mounting on a chassis, the module is optimized for easy installation and maintenance, reducing downtime and simplifying system management.
